MINI CURVE LED Flood Light 10W

Mini Curve LED floodlight is new improved version which is different from the straight type in the market. It develops on the basis of the traditional flood light products, this ultrathin design can save the shipping cost a lot and ensure very convenient installation. Flip Chip COB and SMD 2835 are optional to be 90-100LM/W. Black and white housing are available which are hotsale for supermarket sale, wholesaler,   online sale, project etc. They're CE, ROHS, SAA and ERP approval.



•  >90LM/W
•  Drainage holes in the backside for better waterproof;
•  Excellent appearance with mini-curve patent housing design;
•  Honeycomb-design inside for better heating dissipation;
•  Aluminum alloy die-casting lamp

Model No.	LS-FL150-10W
Power	10W
Lumens	900LM
Light Efficiency	90LM/W
Input Voltage	AC85-240V
Light Source	FLIP CHIP COB or SMD 2835
LED Chip	Epistar
Color Temperature	2700-6500K
CRI	>80Ra
Power Factor	0.95
Hotal Harmonic Distortion	≦0.15
Lens	Tempered Glass
Beam Angle	120°
Key materials	Alluminum Alloy
Body Color	Black/White
IP Rate	IP65
Appliance Class	Class I
Energy Saving	A+
Operating Temperature	-20℃-45℃
Warranty	2 Years
LED Life	>30000hrs
Mounting	Wall/Ceiling Mounting
Certificate	CE, RoHs, SAA





Applications

Factory, warehouse, toll station, gas station, large supermarket, exhibition hall, gymnasium, hall, meeting rooms, shopping malls and other lighting
